Name: Aluminum Square Pipe 10mmin Roudn Shape Down Spout Roll Forming Machine
Brand: BEST
Price: 18000 USD

Brand Name : BEST

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : USD18000---26000

Payment Terms : L/C, T/T

Supply Ability : 20 sets/month

Delivery Time : 30 work days

Production Capacity : 15 M/min

Power : 5.5+3KW

Plant Area : 5000㎡

Width Of The Plate : 330mm

Roller : 22 Rows

22 Rows : 60mm

Contact Now

Aluminum Square Pipe Roll Forming Machine 8 - 10 m/min Production Capacity

Square Pipe Roll Forming Machine Technical Parameters

Power(W):	5.5+3 KW	Weight:	600 kg
Shaft diameter	65mm	Production Capacity:	8-10m/min
thickness of the plate:	0.4-0.6mm	After-sales Service Provided:	Engineers available to service machinery overseas
Voltage:	380V.50HZ.3Phase	Dimension(LWH):	7800X1350X1510mm
Certification:	CE	Warranty:	1 years
control system:	PLC	Frame material:	300 H-high grade steel
Roller station	17 rows	diameter of roller:	80mm
Suitable to Process:	color steel plate,PPGI, galvanized steel sheet, Aluminum plate	width of plate:	330mm
Cutting blade material:	Cr12 mould steel with quenched treatment	Shaft material:	High grade No.45 forged steel ,with 5 nm chrome coated

Note:

Above parameters are standard,we can design and make some change according to your requirement.

Square Pipe Roll Forming Machine Working Flow

Decoiling → Feeding & Guiding → Roll Forming → Cutting → Finished Products To Support Table

Packaging & Shipping

1. Main roll forming machine and un-coiler is maked (If you need, we can also packed it with water-proof plastic)

2. PLC control system and motor pump are packed with water proof paper,spare parts in carton box.

3. One set of machine needs a 40'container to shipping.

MACHINE PICTURE

Aluminum Square Pipe 10m/min Roudn Shape Down Spout Roll Forming Machine

Our Advantage
